VXDIAG A3 Review BMW F18 Coding – Success!

Purpose: VXDIAG A3 multi tool and BMW F series coding

VXDIAG A3 reliable source: https://www.obd2tool.com/goods-6842-ALLSCANNER+VXDIAG+A3+Support+BMW+LAND+ROVER++JAGUAR+and+VW.html

Software: E-sys 3.27.1
ECU: from BMW F18

Test:

IP setup in Itool radar:

13-1
13-2

Run VCXNet DoIP before BMW coding on F series

13-3

Connect VCX: Success

13-4

DoIP on. DoIP: Address IP 192.168.8.170 Port 6811

13-5
13-6

Run BMW E-sys 3.27.1 application

Connect BMW to Vxdiag A3 multi tool

13-7

Check the connection and then confirm to connect

13-8

Coding-> Read-> FA-> Activate FA

13-9

Read SVT

13-10

Select ECU: CAS [40], then do coding

13-11

Coding: done and successful!

13-12
13-13
13-14
13-15
13-16

Result: Success! VXDIAG A3 can work good with BMW F18!

When The launch icarscan app was running, it suddenly stopped

When The launch ICARSCAN app was running, it suddenly stopped. The diagram below:

 icarscan-5
The customer provided the following information:

icarscan-6
Generally, such problems may be caused by too low hardware version or too low car version.



The hardware is automatically upgraded. Only the bluetooth connection box is needed to keep the mobile phone network open, and the App will automatically prompt the firmware to upgrade.



If the hardware upgrade is not resolved, please update your software to the latest version.



If both the hardware and software are upgraded to the latest version, the problem remains. Please provide your icarscan App version and serial number, mobile phone model and android version to us.



We’ll work it out for you in two working days.

OBD2TOOL All rights reserved this article.

Does Autel MaxiSYS Elite have live data and live graphing for abs and crank

4-1

MaxiSys Elite, the newest addition to the MaxiSys line of highly advanced smart diagnostic tools, is based on the fast and intuitive Android operating system. Powered by NVIDIA’s Tegra 4, the world’s fastest mobile processor, its visually stunning 9.7″ Retina display offers ultra-high-resolutions up to 2048×1536 and an optimized array of sophisticated and powerful applications. The Autel Elite rapidly performs every job from comprehensive vehicle diagnostics & analysis to advanced ECU programming. 2x faster than any comparable device, the MaxiSys Elite provides extended battery life and intelligent power saving. The MaxiSys Elite offers a super-sensitive capacitive screen able to respond to gloved, moistened, and even greasy fingers! The ergonomically angled docking station provides optimum visibility and convenient charging that eliminates power concerns.

Does Autel MaxiSYS Elite have live data and live graphing for abs and crank/cam sensors etc.
Answer:
Sure, of course, the most powerful function is it can do ECU coding and programming on BWM,BENZ, and many other powerful special function

Does this Autel Scan Tool cover Lamborghini Aventador?
Answer:
Dear Michael, i’ve checked it for you, this maxisys elite diagnostic tool supports your car Lamborghini Aventador from 2012-2016 ,and here is the software list, you may have a look.

Are the scanners programmed in chinese or english (i have heard they are being shipped programmed in chinese) ?
Answer:
Dear sir, it’s shipped and programmed in English. We sold hundreds of it every month, all customers love it and the device works well.

www.obd2tool.com

The 5 Top Reasons You Need an OBD Scanner On Board

Many things that can go wrong with your car, even if it’s brand new. Sometimes an engine component will malfunction, and you’ll need to understand what’s happened to get it fixed. That’s where an OBD scan tool comes in.

An Best obd2 scanner is a tool that mechanics, auto parts stores, and vehicle manufacturers use to test the mechanics and computer functions in a vehicle. The tool is plugged into your car or truck, then it scans the system for errors.

After that, the scanner provides detailed information so you know how to repair the problem. Sometimes, it’s as simple as ignoring the error message because it was triggered by mistake; other times, it indicates a serious issue with your engine.

Whatever the result of the scan, your OBD tool will give you valuable peace of mind as you drive. With winter in full swing and uncertain road conditions, the last thing you want is to be stranded in the cold.

In many situations, you’ll be very happy you invested in a handy scanner. Here are five of the biggest.

1. Check Engine Light Turns On

14-1

If you paid attention during driver’s education, you’ll recall there’s a variety of lights and indicators on the dashboard, but the scariest is the check engine light. When that indicator blinks on, you were told to pull over as soon as possible and get the problem diagnosed.

Typically, you need to head to the nearest mechanic shop or auto parts store to check the error code and plan for repair. There are a couple of problems with this approach, however.

The first is that you may be in a remote location without a store nearby. It could also be a weekend or the middle of the night, when none of these facilities are open.
You run a risk of damaging your vehicle if you continue to drive it with the check engine light on. In some cases, it could be a non-immediate problem such as a loose gas cap, but in others, it could be your spark plugs, which can lead to more serious damage the longer you drive.

When you have an OBD scanner, you can diagnose the problem wherever you are, whether a freeway shoulder in the middle of nowhere or your driveway. You can read the error code and learn whether it’s safe to drive the car to a mechanic, or you should call a tow to prevent further damage.

The check engine light is not something to trifle with, and your OBD scanner will give you quick and accurate answers.

2. Cold Weather Concerns

14-2

When the temperatures drop below freezing, several things can happen to your vehicle. The battery can die, gas caps can loosen, and your tire pressure can go haywire.

These conditions can cause all sorts of warning indicators to light up your dashboard, including the check engine light. Obviously, that’s cause for concern.

You can make sure your vehicle is in tip-top condition for driving with an OBD scan tool. Any time a warning light flickers on, you’ll have the tool stored in your glove compartment for easy diagnostics.

It will check for key indicators like warning lights, fuel system pressure, engine temperature, exhaust emission levels, throttle response, idle speed, and other key metrics that can show problems in colder temperatures.

Then you’ll know what to have repaired and whether the vehicle’s safe to drive.

3. Your Car or Truck Dies in the Middle of Nowhere

Usually, if your vehicle dies during a long drive, you won’t know the exact reason. By popping the hood, you’ll only see problems that are on the surface. Usually, you need diagnostics to see something deeper.

An OBD scanner can help. Although it might not render specifics about the cause of a malfunction, it can clue you into such things as fuel system pressure and battery levels. It will give you information that can be useful for determining your next step … and in some cases, you may be able to fix it on the spot.

4. You’re Strapped for Cash

The average American spends around 1.5 percent of annual income on auto repairs. That averages to about $600 per car in the U.S., but the number is just an average.

Many people end up spending thousands for vehicle repairs in a year because their vehicle is older and needs more care. The sad thing? Many of the most expensive vehicle repairs can be fixed at home if the owner has the right tools and a decent YouTube tutorial.

An Key Programmer is one of those essential tools, and you can get a decent one for as little as $20. If owning such a tool saves you $600 on car repairs because you were able to diagnose the problem and fix it yourself, you’ll be more than grateful you made the initial investment for a scanner.

5. Manufacturer Recalls

14-3

It’s always a little unnerving when you receive a letter or phone call from your vehicle manufacturer that reports a mass recall of your vehicle’s make and model. Usually, the recalls involve a small and harmless malfunction, but occasional outliers could inflict serious harm on you and the car’s occupants.

Your OBD scanner test for the problem. You can determine whether you should be concerned about your vehicle right away or it can wait a while for the repair. Some factory recalls can take months to address, and you don’t want to drive a car or truck that could “blow up” at any moment.

An Auto Scanner Tool is not only a practical investment, but it buys you peace of mind. For less than $100, you’ll have a car repair tool in your arsenal that will save you money and clue you in on potentially serious issues.

Lonsdor K518ISE Program Renault Scenic III 2015 Smart Card

New test feedback: Lonsdor K518ISE Renault Scenic year 2015 smart key card programming success.

4-1

Select Immobilizer->Renault->Select from vehicle->Megane Scenic-> Scenic III (2009-2015)

4-2

Turn ignition to ON position

Read VIN, detect key number and ID

4-3

4-4

4-5

Insert original key card into key slot

4-6

Follow system prompt to program key

4-7

4-8

Program next key.

Insert new key card into slot and follow Auto Key Programmer Lonsdor K518ISE prompts

4-9

Success.

Test the new smart key.

4-10

Done.



www.obd2tool.com

GM Tech 2 works with Hummer Yes or No

This is about GM Tech 2 scan tool for Hummer troubleshooting and programming.

Can I have a cheap Tech 2 for Hummer?
Yep. Both the original and HQ clone can work for your car.

Where can I get a working clone at a good price?

https://www.obd2tool.com/goods-1568-GM+Tech2+GM+Scanner+-CANdi++TIS+(Works+for+GMSAABOPELSUZUKIISUZUHolden).html

Why my Hummer is not shown in the GM vehicle list?
That little short list is incorrect and only shows a few of the earlier than 2007 CAN bus vehicles.

Tech 2 clone for both troubleshooting and programming Hummer?
I’ve used my Tech2 on my 08 many times for troubleshooting not programming
But I think it should be able to program Hummer.

Anyone has good success of Hummer H3?
My H3 has had a CEL on – po452. I checked it with the tech 2. Well it pulls 3 codes, po455 (large evap leak), po442 (small evap leak), and po449 (vent solenoid control).

Tech 2 is possible to program for Hummer H2 above the year 2007… what to do in that case?

Actually it does the programming just fine on newer than 2007 GM vehicles BUT you must pay for an ACDelco TDS subscription for vehicles above 2007 and you would use the CANDI module that comes with many of the Tech2’s for working with CAN bus vehicles. You can subscribe for it.
This is ONLY needed if you want to program or update the software in a module. ALL of the build in diagnostics and testing for vehicles up to 2013 works without the subscription or the older TIS2000 software. You only need those for doing actual programming. The older TIS2000 software – that is what has the programming was discontinued in 2007. TIS2000 does have the actual programming for all vehicles up to 2007. After 2007 GM went to the TDS system.
You can also get a newer style MDI or MDI 2 for diagnostics and programming. The catch with those. They have NO screen or built in software and you must pay for a subscription from from ACDelco TDS to use an MDI.
Other brand units, a very select few can do actual programming and use the pass-through method. NONE have the diagnostics that the actual Tech2 scanner or GM MDI Scan Tool (with the subscription) will have. Check with Autel and see if they have the full diagnostics and re-calibration for the rear air suspension on a Hummer H2. Not going to happen, there is too little demand for them to hack and reverse engineer that particular bit of code in a Tech2 to figure out the diagnostics and then write programming for that for their tool.

42-1 42-2

FVDI 2018 Tech Support

Professional tech support for FLY FVDI 2018 interface off www.obd2tool.com .

37-1

What is the difference between FVDI 2014 2015 2018?

37-2

Fvdi 2015 has v7 quickloader and it works with the last 2015 fvdi;

FVDI 2018 has software with v2 quickloader including VVDI Functions For BMW and VAG

What cars are covered by FVDI 2018?

V2018 FVDI for TAG, VW, AUDI, BMW, BENZ, Renault, Peugeot, Citroen, Fiat, Ford, Chrysler, Toyota, Nissan, Hyundai, Volvo, mitsubishi motors, porsche, skoda, seat, vauxhall, dacia, jeep, smart, mini, daf, alfa romeo, lancia, infiniti, lexus, scion, kia, maybach

Have software installation problem with V2018 FVDI?
missing mfc110u.dll? Device not opened? Spawn app failed:1?
Installation tips:
1. close antivirus software; connect FVDI to computer via USB;
2. missing mfc110u.dll? Mfc110u.dll errors are caused by situations that lead to the removal or corruption of the mfc110u DLL file, which is a file associated with Microsoft’s Visual Studio software.. please find the “patch” in installation folder, install all the files in “Patch” folder; the problem will be solved;
3. Device not opened? Spawn app failed:1?
You should connect FVDI to computer before software installation; Reinstall the driver manually to solve the problemUSB driver files locate in installation folder “USB interface”.

Installation error fvdi v2018:

37-3

The program cannot start because mfc110u is missing. Dll on the team. Internet reinstall the program to correct the problem

Go to the software installation folder, you’ll find the patch folder, install all files in the folder

: C:\ program files (x86)\abries \ patch

FVDI V2018 with error: “the device has been deactive”

37-4
The Quick Loader V2.0 is out of service, and you have to reinstall V3.0 software!!
V3.0 download link: https://mega.nz/#!KRBzVIrD!uE0ZGjYAbTv0sEZPQjLN0jejex_yI0IF9R3Wad21f7g

Use Chrome browser to download directly, no need install Mega software.

How to renew 722.9 with FVDI Commander Mercedes-Benz?
In order to renew a specific 7-Gear control unit out of the car it is necessary only to connect the CAN pins of the 7- Gear unit, as well as the GND and +12V pins. The wiring of the 7-Gear units is the following:

Pin1: CAN-H

Pin2: CAN-L

Pin4: +12V

Pin5: GND

7-Gear database download link:

https://mega.nz/#!7JJxDAaC!GmjjzZzRY7Bd323ezjiVstQnu_94zQURLE9CIIJrhps

Do you have any good success with FVDI 2018? same sw as 2015?

his 2018 version has the same software versions as the 2015 version except that has updated software for VAG and BMW/Mini which is from the VVDI software. IMMO 4 and 5 key programming is working. Only tested on 2012 Scirocco 2.0 TSi and 2014 Audi A5 2.0T.

Mercedes software still has bugs for odometer correction. W204 did not work.

Overall it is good value for money. Not as good as OBDSTAR X300 DP PAD for keys and odometer but has many better functions like programming and calibrations.

Where to but FVDI 2018 of good quality and at the best price?

Here you go…

https://www.obd2tool.com/category-184-b0-AVDI+ABRITES+Commander.html

37-5

How to active JLR-IMMO OBD Key Programmer

Lonsdor JLR-IMMO New users are required to register, bind and activate the device for the first use. After activation , you can use the device functions.

Users who’ve bound Lonsdor product, can directly enter Email and password to login, no need to register again.

1 Register for website

*    Please enter the website: http://u.lonsdor.com/jlrimmo/login(see below pic)

11-1

*    Click【Register】, it skips to below interface.

11-2

*    According to prompts in frame box, input related info., click【Submit】to register( see below pic).

Input name: fill in user name

Set password: input min 6-digit login password

Confirm password: reconfirm the login password

Input Email: fill in registered email address

Input verification code: click【Get verification code】, then input the correct code.

11-3

2 Website login

*    After register successful, it skips to login interface.
*    Or you can enter the website: http://u.lonsdor.com/jlrimmo/login

According to prompts to input Email, password and verification code, click 【Submit】to login.

11-4

When login succeeds, it skips to “Bind account” interface.

11-5

3 Bind device

According to prompts to input correct info., click【Submit】to bind device.

Device No.: shown on boot screen and back of the device (PSN).

Registration code: after device boot, click A (Enter), there is instruction on activation operation, registration code will show.

Please set device password: 6-digit number

Please confirm device password: confirm the password

11-6

4 Activate device

*    Enter website: http://u.lonsdor.com,(see below pic)

11-7
Users who’ve bound Lonsdor product before, can directly enter Email and password to login, no need to register on the obd2tool.com. Users who doesn’t bind Lonsdor product, complete website registration, then input the registered Email and password to login.

*    After login, the screen shows bound device, see below pic.

11-8

*    Click JLR, see below pic.

11-9

*    Click【Get activation code】, the default in input box is bound device No., see below pic.

11-10

*    Click【Submit】, get activation code, see below pic.

11-11

*    Input activation code to the Key Programming tool, press A(Enter), shown in below pic. Press A(Enter) once again, activation succeeds and enter function interface.

11-12
11-13

SEC-E9 Key Cutting Machine Test on Cutting Silca HU100 Key

SEC-E9 is a powerful key cutting machine,it not only support auto key cutting,but also can cut for house key.And there i show the guide on how to use SEC-E9 to cut Silca HU100 key.

Procedures:

Power on SEC-E9 machine,and press “Search” button.

4-1

Enter “HU100”,then press “Search” button,select “SILCA”

4-2

Select “HU100(1097)(8-8)”

Press menu button,and press “info” button to know the basic information.

This key is guided by “Tip”

Then close the window

4-3

Press “decode” to enter the decoding page

4-4

Click the image of three-terminal positioning and press “Round off”

4-5

Check if the original key can work well

4-6

Fix the original key on car key clamp

4-7

Please note the key should be fixed level.

4-8

4-9

Press “decode”,and click the picture of “Clean the groove from chips” to start decoding.

4-10

Take away the original key

Fix a HON66 key blank on car key clamp.

Please not the key blank should be fixed level

4-11

Click “cut” button to enter cutting page

4-12

Press “Speed” and “Normal resolution” button.

4-13

Click the image of three-terminal positioning

You can adjust the cutting depth,usually it is 1mm.

4-14

Press “Cut” button to start cutting.Please remember to close the safe gate.

4-15

Cutting…

4-16

Cutting is done.

Open the safe gate.Clean the clamp,and take out the new key.

4-17

Change the other side of the key blank on the car key clamp for cutting,click “cut” button and close the safe gate.
4-18

4-19

Cutting…

4-20

Cutting is done,open the safe gate and take out the new key by OBD II Scanner.

Try your new key if the new key works.

4-21
